Product Description
APPLICATIONS
● Gigabit Ethernet
● Telecommunication networks
● Active device termination
● Video
● Industrial
● Multimedia
● Premise installations
AVAILABILITY
● Simplex/Duplex patch-cord available
● LC/PC & LC/APC patch-cord available
● Pigtail available
● Various boot (cable) sizes available
SPECIFICATIONS
FEATURES
● High temperature stability
● Good exchangeability
● Good Durability
● Low insertion loss and back reflection loss
Single mode | Multimode | |
Insertion Loss | ≤0.20dB | ≤0.25dB |
Return Loss | ≥50 dB (PC) ≥65 dB (APC) | |
Repeatability | ≤0.1 | |
Durability | ≤0.2 dB typical change, 1000 matings | |
Interchangeability | ≤0.2dB | |
Tensile strength | >10kg | |
Operating Temperature | -40 to + 85°C | -40 to + 85°C |
Straight pull | installation: 200N，Operation: 100N
| |
Crush | Immediately: 500N/cm，Frequency: 100N/cm | |
ORDERING OPTIONS
Boot(cable)Size | Boot Color | Fiber Type | Cable number | Application | Length |
0.9mm | Beige | 9/125µm (SM) | Simplex | PC | Customized |
2.0mm | White | 50/125µm (MM) | Duplex | APC | |
Blue | 62.5/125µm (MM) |
Customized Service
